DNA100
Art.-Nr.: DNA100
Request now Project consulting

XTA is a leading professional audio company based in the UK. With a history stretching back over 25 years and being at the forefront of DSP technology, XTA design and manufacture professional amplification and digital audio management products used extensively around the world in both live touring and installed applications. Thanks to the company’s background in live production audio XTA has a wealth of knowledge in just what’s required to produce the highest quality audio with the best processing and simplest (stress-free) control. All XTA products are covered by a 5-year warranty.

Overview

4x 2700 W Digital Network Audio Power Amplifier

The DNA Series offers the assurance of XTA’s highest quality audio power amp technology with future proofing via the inclusion of simple to use digital audio networking.

Accepting analogue, or optional Dante networked audio, this extra connectivity means that the all DNA models can also be used in installation systems which already have a centralized DSP core but require the flexibility of being able to pick up multiple channels of audio from a network.

With a range of power levels available in the DNA Series, the amplifiers can be networked to a single DPA model, creating a powerful, efficient system that’s easy to expand and adapt for use in live, install and everything in between.

Running cool in even the most difficult conditions, the DNA40 can deliver 4x 2700 W into 4 ohms with all channels driven, and an substantial 2x 5400 W bridged (8 ohms), with outstanding distortion and noise figures right up to maximum output.

Product Details

  • Network Class D amplifier
  • 4x 2700 W at 4 ohms, bridgable: 2x 5400 W at 8 ohms
  • 4x analog Inputs
  • Optional Dante Card available
  • 32 dB gain
  • Dimensions: 88 (H) x 482(W) x 428(D) / 2 U
Number of channels
4
Input Impedance
20k ohms
Input CMRR (dB)
> 60
Damping Factor (1kHz, 8 ohms)
> 400
Output Power (per channel)
1400W / 8 ohms, 2700W / 4 ohms, 3700W / 2.7 ohms, 3500W / 2 ohms
Output Power
(bridged): 5400W / 8 ohms, 7000W / 4 ohms
THD% (@1dB below max output)
< 0.08% ( 1kHz), < 0.1% (20Hz to 20kHz)
Gain
32dB
Sensitivity (for max power)
10.7dBu
Frequency Response
20Hz to 20kHz (+ 0/- 0.5dB)
Power supply
115/230AVC
Power Consumption
7.5 A , < 5W in standby), 20 A (max.)
Dimensions
88 (H) x 482(W) x 428(D) / 2 U
Weight
10.8kg
